C97K Impact Window System

Design features

• Slim profiles for maximum glass area and daylight
• Impact-resistant system engineered for coastal and hurricane-prone regions up to 125 PDF DP
• Fixed, casement, awning, and combination window configurations
• Large opening sizes with optimized structural performance
• Multi-point locking hardware on operable units
• Durable aluminum construction with premium architectural finishes
• Designed for superior air, water, and structural performance

Options

• Fixed, casement, awning, and combination window configurations
• Single-unit, mulled, and custom assembly arrangements
• Impact-resistant laminated and insulated laminated glazing options
• Multiple frame finish selections, including White, Black, Bronze, and Clear Anodized
• Large glass openings with optimized sightlines for maximum daylight
• Left- and right-handed operable configurations
• Optional open-position visualization for operable units
• Compatible with a wide range of architectural applications and installation conditions

Application type

Ideal for luxury residences, waterfront homes, multifamily developments, and commercial projects seeking expansive views, natural daylight, and certified impact protection.

Technical Data

• Frame Depth: 3.86" (98 mm)

• Maximum Frame Width: Up to 144"

• Maximum Frame Height: Up to 144"

• Glazing Thickness: Up to 1.26" (32 mm)

• Configuration Types: Fixed, Casement, Awning, Combination

• Frame Material: Extruded Aluminum Alloy

• Available Finishes: White, Black, Bronze, Clear Anodized

• Glass Options: Laminated, Insulated Laminated

• Hurricane Impact Resistance: Yes

• Water Resistance: Tested per ASTM standards

• Air Infiltration: Tested per ASTM standards

• Structural Performance: Tested per ASTM standards

• Installation Options: Wood Buck, Concrete, CMU, Frame Construction

• Hardware: Multi-Point Locking System

• Handing Options: Left-Hand and Right-Hand Operation


• Design Pressure: +/- 125 PSF

• Florida Product Approval: Pending

• Miami-Dade NOA: Pending
